Host a static website with your own domain, AWS S3 and CloudFront

With AWS (and in particular the free AWS contingent) you have the option of a static website with a custom domain for a few Hosting cents a month including CDN via CloudFront and CI / CD integration.

Before I switched completely to AWS, I had a common shared hosting option that cost me around € 72 a year. With this option I had

• 250 GB SSD storage space,
• free unlimited traffic,
• 6 domains included,
• 250 GB SSD mail storage space,
• 25 MySQL databases,
• and, and, and.

On the whole, much more than I need to run my static GatsbyJS website.

So why shouldn't I only use and pay for resources that I ultimately need and also get some cloud computing experience?

Creating S3-Buckets

The basis for hosting on AWS is formed by S3 Buckets. Buckets are "containers" on the web where you can save files. In order for redirects from subdomains such as www.mxd.codes to mxd.codes to work, you need a bucket for each domain.

First of all, you create an S3 bucket for the root domain. In my case, the bucket name is the domain name mxd.codes and you select a region (for example EU (Frankfurt)). The default settings can be kept under Options, unless you want to save different versions or access protocols. So that everyone can access the website content later, remove the tick that is present by default at "Block any public access", check the bucket settings again and finally create it.

In each bucket you can or should enter a bucket policy that further defines access. To do this, click on the name of the bucket and go to "Permissions" -> "Bucket Policy".

The following guideline must then be saved for public access.

json
Copy code
{
    "Version": "2008-10-17",
    "Statement": [
        {
            "Sid": "AllowPublicRead",
            "Effect": "Allow",
            "Principal": {
                "AWS": "*"
            },
            "Action": "s3:GetObject",
            "Resource": "arn:aws:s3:::mxd.codes/*"
        }
    ]
}

"mxd.codes" has to be replace with your bucket name!

If everything was done correctly, the permissions should now look something like this:

Sorry, somehow the image is not available :(

In the bucket settings you have to activate the "hosting a static website" and specify an index document and an error document. For GatsbyJS that would be index.html and 404.html.

Sorry, somehow the image is not available :(

Now the S3 bucket for the subdomain www.mxd.codes is still missing. So create a new bucket with the name of the subdomain www.mxd.codes with public access and add the bucket policy.

In the settings for "hosting a static website" you use "redirect requests" and enter the target bucket mxd.codes and you can enter https as a protocol, because later on the content of the static website is delivered via CloudFront, which can be encrypted with SSL certificates.

Sorry, somehow the image is not available :(

The buckets are now created and correctly configured for the operation of a static website including redirect.

CloudFront Distributions

With the free AWS contingent, 50 GB of data transfer can be burned per month in Cloudflare.

With a page size of generous 4 MB, this is enough for 12,500 page views per month and should therefore be more than sufficient for a website with average traffic. So why not take a free CDN with you?

If the costs incurred after the free year should deter someone, you still have the option to switch to another CDN provider such as CloudFlare.

At CloudFront you have to create a web distribution for each bucket. As the origin domain name, a bucket can not be selected from the dropdown list, but the end point of the bucket from S3 must be copied.

Sorry, somehow the image is not available :(

In the distribution for the bucket mxd.codes, for example "mxd.codes.s3-website.eu-central-1.amazonaws.com" is specified as origin. "Origin ID" will then be filled in automatically. In "Viewer Protocol Policy" Redirect HTTP to HTTPS is selected because users should only be able to access the website via HTTPS. "Compress Objects Automatically" Yes can be selected, so that CloudFront will zip all files automatically. Under "Alternate Domain Names (CNAMES)" you have to specify the bucket for the root domain for the distribution for the root domain. For example mxd.codes

At "SSL-Certifacte" you can now create for the two domains mxd.codes and www.mxd.codes two free Amazon SSL certificate via the Certificate Manager (ACM ). To do this, add your two domains in ACM.

Sorry, somehow the image is not available :(

You can now have this validated using a DNS or email method. If you have included your domain in Route 53, you can do it more or less automatically by simply following the instructions.

Back in the CloudFront Distribution Creation you only have to specify a "Default Root Object". -> index.html If you don't do this, CloudFront always shows an "Access Denied" message in XML format when you access your domain (atleast that was my case).

Finally, the distribution must of course still be activated under "Distribution State".

First distribution finished. The same procedure now for the subdomain www.mxd.codes with the corresponding "Origin Domain Name" (Bucket end point!)

This can take up to 20 minutes (If you want to clear your CloudFront cache and have already installed AWS CLI, you can do this with the following command:

shell
Copy code
aws cloudfront create-invalidation --distribution-id DEINE_DISTRIBUTION ID --paths "/*"

In the meantime, you can create the redirects for Cloudfront in Route 53.

Route 53 DNS settings

In [Route 53]("Route 53") you need a hosted zone (= 0.50€ per month). Then A (and provided that in the CLoudFrontDistribution IPv6 is activated (which it is by default), as well as an AAAA) data record can be created.

That means you basically need 4 "alias" data sets:

• mxd.codes A "CloudFront URL for root domain"
• mxd.codes AAAA "CloudFront URL for root domain"
• www.mxd.codes A "CloudFront URL for subdomain"
• www.mxd.codes AAAA "CloudFront URL for subdomain"

Exceptionally, you can select the CDN url from the dropdown list. With "Routing Guideline" and "Assess the state of the target" you can leave the default settings, unless you want to experiment.

Now if you wait a little you should be redirect from

• http://wwww.mxd.codes,
• https://wwww.mxd.codes,
• wwww.mxd.codes,
• http://mxd.codes and
• mxd.codes to https://mxd.codes .
