2021-03-02 i started tracking my current location with OwnTracks and Strapi (How i constantly track my location and display a web-map with all the locations) and created a /map which shows all the locations i have ever been to. Recently i reached one million datasets and unfortunately that means every user had to download about 50MB of location data before the map could be rendered. So i definitely needed a much faster solution and decided to render and serve server side some tiles which will be used to display the locations. In the end i built a tile-server following Manually building a tile server (20.04 LTS) with a custom Mapnik stylesheet.

In this article i want to show you how you can build your own Mapnik stylesheet for displaying any data from PostgreSQL/PostGIS.

The Mapnik stylesheet XML is not very handy but fortunately there are some tools which will help you to create one. After some research i decided to go with TileMill which is an open source map design studio to design maps. It offers a simple UI and (more important) the possibility to export the created map-style as Mapnik stylesheet.

Actually i couldn't get the latest version running so i decided to go with TileMill v0.10.1 which offers anything you will need to create a stylesheet. At https://tilemill-project.github.io/tilemill/docs/win-install/ you can download and install TileMill.

After you have installed TileMill you can create a new project and uncheck 'default data'. Otherwise TileMill will create some kind of basemap with a default style.


Now you will have to add some data to the project. Therefore you click on the layer button and add a new layer.


Switch to the PostGIS tab and fill out ID, Connection, Unique key field, Geometry field and SRS. It's actually pretty straight forward. Keep in mind that TileMill doesn't like large datasets so i would recommend you to set some extent.

In SRS you have to specify the PROJ.4 projection string. If you don't it know a look at https://epsg.io/{epsg-code} where you will replace {epsg-code} with the epsg code of your coordinate system and scroll down to PROJ.4 where you can copy the projection string.

proj4.png Afterwards save the layer and the project. You won't see your data/features yet because you need to define some style for it. You can style the map with CartoCSS which is very similiar to CSS. For example i specified my layer id as locations and i am styling points so the CartoCSS properties could look like the following.

#locations {
   [vel >= 0] { marker-width:6; marker-fill: #f45; marker-line-color: #813; marker-allow-overlap: true; }
   [vel >= 50] { marker-width:6; marker-fill: #f45; marker-line-color: #813; marker-allow-overlap: true; }
   [vel >= 100] { marker-width:6; marker-fill: #f45; marker-line-color: #813; marker-allow-overlap: true; }
}

With CartoCSS you can also dynamically style your features depending on some attribute values. For more information about CartoCSS have a look at Styling data from TileMill.

When you are happy with your style you can export if as Mapnik-XML and use if for example for your tile-server.


At /map you can see my current stylesheet in 'action'.
